Micro:bit V1.5 (Copy Version) set without battery

SKU: FA1076-1
Main Processor

Nordic nRF51822 (ARM Cortex-M0 @ 16MHz)
Memory

256KB Flash / 16KB RAM
Display

25 Red LEDs in a 5×5 Grid
Input Controls

2 Programmable Buttons (A/B) + System Reset
Sensors

3-Axis Accelerometer & Compass (Magnetometer)
Interface

Micro-USB (Programming & Power)
Standard Connectors

JST-PH (3V Battery Input) + 20-pin Edge Connector
Dimensions

52mm x 43mm
The Micro:bit V1.5 (Copy Version) Lite Set remains a staple for high-volume educational deployments and industrial IoT prototyping. This specific “Set without Battery” configuration is designed for organizations that already possess power infrastructure or for international shipping where battery restrictions may apply.
Long Product Description
The Micro:bit V1.5 (Copy Version) is a cost-effective, high-quality alternative to the original V1 series, maintaining 100% hardware and software parity. Powered by the Nordic nRF51822 (ARM Cortex-M0), this board is the perfect entry point for learning hardware-software interaction. It features the classic 5×5 red LED matrix, dual programmable buttons, and a suite of motion sensors (accelerometer and compass).
This “Lite Set” includes the essential Micro:bit V1.5 board and a Micro-USB data cable. By excluding the battery pack, this kit offers a slimmer profile for storage and lower shipping costs, making it the preferred choice for business procurement, corporate workshops, and schools that primarily use computer-tethered USB power for their coding curriculums. It is fully compatible with Microsoft MakeCode, MicroPython, and Scratch.
Key Features
  • Full Software Compatibility: Works seamlessly with all official editors (MakeCode, Python, Scratch) and thousands of existing V1/V2 expansion shields.
  • Triple Wireless Connectivity: Integrated Bluetooth Low Energy (BLE), 2.4GHz proprietary radio, and a built-in antenna for wireless interaction.
  • Onboard Sensor Suite: Includes a 3-axis accelerometer for motion/shake detection and a magnetometer (compass) for orientation.
  • USB Programmable: Features a dedicated NXP interface chip for simple drag-and-drop programming—no specialized drivers required.
  • Edge Connector Access: 20-pin gold-plated interface allows for easy “clip-on” expansion with crocodile clips or 0.1″ pitch headers.
  • Business-Ready Packaging: Typically shipped in neutral, anti-static industrial packaging to minimize waste and reduce bulk for B2B buyers
Usage Instructions
  1. Connecting: Plug the Micro:bit into your computer’s USB port using the included cable. It will appear as a removable drive named “MICROBIT.”
  2. Coding: Navigate to the MakeCode Editor or Python Editor in any web browser.
  3. Downloading: Write your program and click the “Download” button to save a .hex file.
  4. Transferring: Drag and drop the .hex file into the “MICROBIT” drive. The status LED on the back will blink during the process.
  5. Running: The board will automatically reboot and execute your code once the transfer is complete
Q: Why does this set not include a battery?

This configuration is designed for Business-to-Business (B2B) purchasing and international logistics. Removing the battery simplifies air freight regulations and reduces the per-unit cost for classrooms that primarily use USB power from laptops or tablets.

Q: Can I add my own battery later?

Yes. The board features a standard JST-PH (2-pin) connector. You can connect any 3V power source (such as a 2xAAA battery holder) to make your projects portable

Q: Is the "Copy Version" as reliable as the "Official" version?

Yes. The V1.5 (Copy Version) uses the same core Nordic nRF51822 architecture. It is built to the same industrial standards and is widely used in high-volume STEM programs globally due to its reliability and lower cost

Q: Can this board run V2-exclusive features like sound or voice?

No. This is a V1.5 architecture. It does not have the built-in speaker or microphone found on V2 boards. However, it is fully capable of all standard motion, light, and Bluetooth-based coding tasks

Q: Is it suitable for professional IoT prototyping?

Absolutely. Many businesses use this version to prototype low-power BLE sensor networks or industrial telemetry tools before moving to a custom PCB, as the software developed here is directly portable to the nRF51 series

Q: What is the lead time for bulk business orders (100+ units)?

Because this is a high-volume neutral-packed item, we typically maintain large stock levels. Standard lead times for 100-500 units are usually 3-5 business days. Please contact our corporate sales portal for a formal quote.
