Photoelectric encoder/speed sensor encoder Smart car C B D E car model

SKU: FA3016-3

$3.01

Weight 0.029 kg
Number of lines:

100 lines

Outer diameter:

22mm

Bore Diameter:

3.5mm

Thickness:

0.3mm

Material:

Steel

Production process:

Laser Cutting

Supply voltage:

5V

Wiring:

Red-5V Black-GND

Output Signal:

5Vp-p two quadrature signal output

500 in stock

Code disk Technical parameters:

Brand new and high quality.

  • Number of lines: 100 lines
  • Outer diameter: 22mm
  • Bore Diameter: 3.5mm
  • Thickness: 0.3mm
  • Material: Steel
  • Production process: Laser Cutting
  • Speed of pipe technical parameters:
  • On the tube Manufacturer: Original
  • Supply voltage: 5V
  • Wiring: Red-5V Black-GND
  • Output Signal: 5Vp-p two quadrature signal output

Important note:For a long time to hold backorDo not block allNo output, as the phase detection, only in the correlation of the rising and falling output waveform, so turn the encoder or switch back and forth with opaque object state when the square wave output, high speed condition, similar to sine wave and sawtooth wave, as shown in the video demonstration below.Multimeter test have been about 0.1 V, it is useless!Test, please useThe oscilloscopeorSinglechip collection.
